防火墙

vm64模式SeaBIOS vyos1.2.9路由器

基础路由应用

至少3个口一个管理口，一个lan，一个wan 。端口映射，vlan，ospf,upnp，

命令行管理

第一个物理口 mgmt (通常用于管理)

show 看配置 get 看状态

查看命令

show full-configuration
show full-configuration system interface mgmt

get system interface physical

get hardware status
get system status
show system global
get system inter   显示ip
show system inter  显示配置
get route info routing-table all #按tab补全
show route static

get hardware cpu
get hardware memory
get system performance status

get system interface physical  #硬件接口
get hardware nic  #硬件接口

get system arp
get system arp
get system fortiguard-service status
get system stp list

配置命令

配置ip

config system interface
    edit "mgmt"
        set vdom "root"
        set mode static
        set ip 192.168.129.111 255.255.255.0
        set allowaccess ping https ssh snmp http
        #set role lan
        set type physical
    next
end

show system interface mgmt

配置路由

静态指向路由

config router static
    edit 1
        set dst 192.168.0.0 255.255.0.0
        set gateway 192.168.122.1
        set device "mgmt"
    next
end


show router static

系统路由表

get router info routing-table all

dns配置


config system dns
    set primary 8.8.8.8
    set secondary 96.45.46.46
    set protocol cleartext dot
    set server-hostname "globalsdns.fortinet.net"
end
show system dns

测试命令

execute ping 8.8.8.8
traceroute 8.8.8.8
execute reboot

虚拟vlan

config system switch-interface
    edit "sw1"
        set vdom "root"
        set member "port2" "port3"
        set type switch
        set intra-switch-policy implicit
        set mac-ttl 300
        set span disable
    next
end

config system virtual-switch
    edit "VLAN10"
        set physical-switch "sw0"
        set vlan 10
        config port
            edit "port1"
            next
            edit "port2"
            next
        end
    next
   end

虚拟机配置

BIOS模式，网口必须是virtio类型

登入密码

终端默认登入密码

默认用户名为 admin ，默认密码为空。
